The new AWD frame set with separate receiver unit for use with your choice of transmitter joins the EVO series range!
The detachable receiver design pioneered on the MR-03EVO is now available with the new AWD MA-030EVO model, based on the FWD MA-03F chassis. The MINI-Z was originally designed with an integrated receiver, servo and speed controller, however on the MR-030EVO the receiver was designed to be purchased and installed as a separate unit to allow the model to be used with other brands of transmitters. such as KYOSHO (KT18 / EX-6 / EX-6R / KT-531P / KT-432PT), KO (EX-2 / EX-RR), Futaba (T7PX / T7XC / T4PM), Flysky (Nobile NB4). Additionally, the higher specification AWD MA-020VE PRO series included a 3-stage steering servo unit, but the new MA-030EVO includes the even higher specification 5-stage gear type than the MR-03. Also, a special servo CPU improves positioning feedback control speed, and the updated control program delivers the best steering feel of any AWD model thanks to improved responsiveness and linear response to driver control. The one-piece heat sink and aluminum housing of the KYOSHO SPEED HOUSE XSPEED 85 (8500KV) brushless motor keep it cool for optimum performance. The ICS manager allows for fine adjustments of settings and even switching to a brushed motor, which was not possible with previous frame sets. Switch from driving style to drift and grip to experience the ultimate in AWD driving performance. manager allows fine adjustments of settings and even switching to a brushed motor, which was not possible with previous frame sets. Switch from driving style to drift and grip to experience the ultimate in AWD driving performance. manager allows fine adjustments of settings and even switching to a brushed motor, which was not possible with previous frame sets. Switch from driving style to drift and grip to experience the ultimate in AWD driving performance.
● The MA-030 AWD chassis is based on the MINI-Z FWD MA-03F chassis.
● The frame set comes with separate ESC and receiver unit.
● Includes KYOSHO SPEED HOUSE 85 (KV8500) brushless motor.
● ICS manager allows precise control of settings and the use of brushless or brushless motors.
● Independent CPU control with faster processing speed gives you even more precise control.
● Comprehensive ball bearing specification reduces transmission loss.
● Includes double wishbone rear suspension.
● Compatible with L （94mm） and LL （98mm） center distances. Only LL （98mm） can be used with the double wishbone rear suspension set.
● Compatible with optional parts for various MR-03F chassis models
Specifications
* Scale: 1 / 27.6
*Length:
126.0mm * Width: 65.0 - 76.0mm (adjustable according to wheel offset)
* Height: 36.0mm
* Frame type: MA-030
* Wheelbase: 94.0mm (only with rear strut suspension installed), 98.0mm (factory assembled)
*Weight:
135 g * Brushless 8500KV
* Transmission ratio: 7.2, 6.4, 6.0, 5.7, 5.3, 5.0, 4.5: 1
* Tire diameter (F / R): sold separately
* Tire width (F): sold separately
* Tire width (R): sold separately
* Transmitter: not included
* Maximum speed: approx. 17 km / h
* Duration: approx. 50 min.
CONTENTS OF THE CHASSIS SET
* Factory assembled chassis with EVO main unit installed
* Sprockets (15T, 17T, 19T, 21T)
* DWS Conversion Parts * Front Tread Conversion Parts
* Tool for removing the pinion
*Dice
spare wheel * Wheel wrench
* Central shaft for L pitch
* Wide rear suspension arms for DWS
* swing shafts (4 x long)
* Spur gears (27T, 29T, 31T)
NECESSARY FOR OPERATION
* 8 AAA batteries
* Automatic scale collection (bodywork, wheels and tires)
*Transmitter
* MINI-Z EVO receiver unit compatible with the transmitter used
